Graphite Electrode Product Parameters
| Nomina diameter | RP | HP | UHP | ||||
| Current Carrying Capacity | Current Density | Current Carrying Capacity | Current Density | Current Carrying Capacity | Current Density | ||
| in | mm | A | A/cm2 | A | A/cm2 | A | A/cm2 |
| 12 | 300 | 10000-13000 | 14-18 | 13000-17400 | 17-24 | 15000-22000 | 20-30 |
| 14 | 350 | 13500-18000 | 14-18 | 17400-24000 | 17-24 | 20000-30000 | 20-30 |
| 16 | 400 | 18000-23500 | 14-18 | 21000-31000 | 16-24 | 25000-40000 | 19-30 |
| 18 | 450 | 22000-27000 | 13-17 | 25000-40000 | 15-24 | 32000-45000 | 19-27 |
| 20 | 500 | 25000-32000 | 13-16 | 30000-48000 | 15-24 | 38000-55000 | 18-27 |
| 22 | 550 | 32000-40000 | 13-16 | 35000-55000 | 14-22 | 42000-64000 | 17-26 |
| 24 | 600 | 35000-41000 | 13-15 | 41000-61000 | 14-21 | 50000-73000 | 17-25 |
| 28 | 700 | 39000-48000 | 10-12 | 55000-82000 | 14-21 | 67000-99000 | 17-25 |
| 32 | 800 | 43000-54000 | 8-10 | / | / | / | / |
Welcome to contact us for quotation.
Address:Huafu Commercial Center, Wenfeng District, Anyang City, Henan Province, China
The EAF electrode (typically graphite-based) is the linchpin of Electric Arc Furnace (EAF) operations, serving as the primary interface between electrical power and the thermal/mechanical processes required for steelmaking. These electrodes are not passive conductors but active tools that directly influence EAF efficiency, product quality, and operational costs.
Energy Conversion: EAF electrodes transmit high-amperage current (up to 120 kA) to the furnace, where it generates an electric arc (3,000°C+) to melt scrap, DRI, or hot metal. This process converts electrical energy into thermal energy with 90–95% efficiency.
Arc Control: By adjusting electrode height (via automated hoists), operators regulate arc length and current, directly controlling heat input. This precision minimizes energy waste (targeting 500–600 kWh/ton) and prevents bath overheating (which degrades refractory linings).
Metallurgical Catalyst: Current flow induces eddy currents in the molten bath, enhancing mixing between steel and slag. This accelerates desulfurization (S <0.005%), deoxidation (C reacts with O), and inclusion removal, critical for producing high-grade steel (e.g., automotive, aerospace).
Technical Specifications
Material: High-purity graphite (carbon >99.5%, ash <0.5%) ensures low resistivity (15–25 μΩ·m) and minimal metal contamination.
Mechanical Properties: Compressive strength >70 MPa and flexural strength >25 MPa withstand stacking weights (up to 6 electrodes, 3 meters long) and arc-induced stress.
