Furnace Graphite Electrode for steel making
| ITEM | Regular power | High Power | Ultra high power | ||||
| UNIT | 3-24inch | 4-24inch | 14-24inch | 12-20inch | 22-28inch | ||
| φ75-600mm | φ100-300mm | φ350-600mm | φ300-500mm | φ550-700mm | |||
| Resistivity | Electrode | μΩ*m | 7.0-9.0 | 5.8-6.8 | 5.5-6.5 | 4.8-5.8 | 4.5-5.5 |
| Nipple | 4.0-4.5 | 4.0-5.0 | 3.5-4.0 | 3.0-4.0 | 2.5-3.5 | ||
| Bending strength | Electrode | MPA | 8.0-12.0 | 9.0-12.0 | 10.0-14.0 | 10.0-15.0 | 12.0-16.0 |
| Nipple | 19.0-22.0 | 16.0-20.0 | 20.0-23.0 | 20.0-24.0 | 22.0-25.0 | ||
| Elastic Modulus | Electrode | GPA | 7.0-11.0 | 8.0-12.0 | 8.0-12.0 | 9.0-13.0 | 10.0-14.0 |
| Nipple | 12.0-14.0 | 12.0-15.0 | 14.0-16.0 | 15.0-18.0 | 16.0-19.0 | ||
| Bulk density | Electrode | g/m3 | 1.60-1.65 | 1.68-1.7 | 1.68-1.72 | 1.70-1.75 | 1.70-1.75 |
| Nipple | 1.75-1.8 | 1.78-1.82 | 1.78-1.82 | 1.78-1.85 | 1.8-1.85 | ||
| Ash | Electrode | % | 0.3 | 0.3 | 0.3 | 0.2 | 0.2 |
| Nipple | |||||||
| CTE (100-600ºC) |
Electrode | 10-6/ºC | 2.0-2.4 | 1.6-2.0 | 1.6-1.9 | 1.1-1.4 | 1.1-1.4 |
| Nipple | 1.8-2.2 | 1.1-1.5 | 1.1-1.4 | 0.9-1.2 | 0.9-1.2 | ||
Welcome to contact us for quotation.
How should steel mills properly store and handle 200mm diameter graphite electrodes?
Graphite electrodes are brittle and sensitive to bumps and moisture. Improper storage and handling can result in serious damage:
• Storage: They must be stored in a dry, flat warehouse with sleepers placed underneath. The number of stacking layers is strictly limited. Open-air storage, where they may be exposed to rain and moisture, is strictly prohibited.
• Handling: Special lifting equipment (such as flexible nylon slings) must be used. Direct hooking or lifting with wire rope is strictly prohibited. Prevent any collision, drop, or rolling.
• Pre-use Inspection: Before use, inspect the threads and body for cracks, bumps, or other damage. Wet electrodes must be dried before use; otherwise, they will burst instantly when placed in a high-temperature furnace.
One-Stop Service for Quality Assurance
Our technicians are trained engineers with expertise in EAF, ladle, and casting applications. We provide comprehensive support for ultra-high-power graphite electrodes, including:
Inspection and analysis of customer furnace conditions to enhance electrode performance and reduce consumption.
Additional services such as staff training, performance analysis, warehouse storage, accessory inspection, and furnace monitoring.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
