RP Hp UHP dia 500 graphite electrode for arc furnaces
| UHP Graphite Electrode | |||||||
| Item | Unit | Diameter | |||||
| Φ300 | Φ300-Φ350 | Φ400-Φ500 | Φ550 | Φ600 | Φ650-Φ700 | ||
| Electric resistivity≤ | μΩm | 5.50 | 5.50 | 5.50 | 5.50 | 5.50 | 5.50 |
| Flexure strength≥ | Mpa | 12.00 | 12.00 | 12.00 | 12.00 | 12.00 | 12.00 |
| Modulus of elasticity≤ | Gpa | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 |
| Bulk Density≥ | g/cm3 | 1.69 | 1.69 | 1.69 | 1.69 | 1.69 | 1.69 |
| CTE(100-600ºC) ≤ | x10-6/ºC | 1.40 | 1.40 | 1.40 | 1.40 | 1.40 | 1.40 |
| Ash Content ≤ | % | 0.30 | 0.30 | 0.30 | 0.30 | 0.30 | 0.30 |
Welcome to contact us for quotation.
What is the role of 500mm graphite electrodes in energy storage systems?
In energy storage systems, particularly those involving advanced electrochemical technologies, 500mm graphite electrodes are utilized for their excellent conductivity and stability. Though not as common as in steelmaking or electrolysis, large-diameter graphite electrodes can be employed in specialized energy storage devices like flow batteries or large-capacity supercapacitors where high charge/discharge efficiency is crucial.
The 500mm size facilitates better current distribution across a larger surface area, which is beneficial in systems requiring stable and sustained energy transfer. Graphite's natural ability to intercalate lithium also makes it valuable in research and development of next-generation battery technologies. These electrodes are chosen for their long cycle life, chemical inertness, and ability to withstand numerous charge-discharge cycles without significant degradation.
Although still emerging, the application of 500mm graphite electrodes in energy storage highlights the material's versatility beyond traditional industries and its potential contribution to sustainable energy solutions.
